The REVO HES Series is an industrial-grade single-phase hybrid energy storage inverter designed for demanding outdoor environments. Offering power options of 6kW, 8kW, and 10kW, this series features an IP66 rating for superior protection against dust ingress and powerful water jets, enabling worry-free outdoor installation. Combining grid-tied and off-grid functionality, it intelligently integrates and manages multiple energy sources including solar PV, utility grid, generators, and batteries. Convenient management is facilitated through an LCD touchscreen and remote app. Backed by a 5-year warranty and supporting up to 6 units in parallel, it delivers a highly reliable, easily scalable smart energy solution for both residential and commercial users.
1. IP66 Ultra-High Protection, Conquering Outdoor Challenges
Technical Core: Achieves IP66 protection rating (complete dustproofing and resistance to powerful water jets) with a wide operating temperature range of -25°C to 50°C.
User Value: Directly installable in outdoor environments without requiring additional waterproof enclosures or equipment rooms, significantly saving installation space and costs while ensuring stable operation under extreme climates.
2. 5-Year Extended Warranty for Worry-Free Investment
Technical Core: Comprehensive 5-year manufacturer warranty provides long-term quality assurance.
3. Dual-Mode Intelligent Switching & Generator Standby
Technical Core: Supports seamless grid-connected/off-grid switching (<10ms) with dedicated generator input port. Forms quadruple power assurance with utility grid, PV, and batteries.
User Value: Ensures uninterrupted operation of critical loads under all conditions.
4. Smart Energy Management and Economic Optimization
Technical Core: Features flexible time-of-use (TOU) rate management, enabling remote monitoring and control via LCD touchscreen, mobile app, and web interface.
User Value: Automatically executes “off-peak charging, peak-time discharging” strategies to maximize electricity cost savings.
5. Flexible System Parallel Expansion Capability
Technical Core: Supports parallel operation of up to 6 inverters from the same series, with compatibility for networking different power models (e.g., 6kW and 10kW units).
User Value: Enables seamless capacity expansion to meet growing electricity demands.
6. Full-Scene Battery Compatibility and Safety Design
Technical Core: Compatible with both lithium-ion and lead-acid batteries, featuring dedicated BMS communication interfaces (RS485/CAN). Incorporates multiple safety protections including physical and electrical isolation, insulation detection, and anti-islanding.
User Value: Comprehensive safety mechanisms ensure protection for equipment, batteries, and personnel, compliant with international safety standards (EN/IEC 62109) for enhanced operational peace of mind.
SOROTEC Company specializes in the research, development, manufacture and sale of solar energy products.
